Part  Number

Item  Name

CAP

Voltage  (DC)

D

W

H

B

T

CC683

Drawn Oval Can

1 µF

2000 V

1.31 in

2.19 in

3.75 in

2 in

0.81 in

CC684

Drawn Oval Can

2 µF

2000 V

1.91 in

2.91 in

3.75 in

2 in

1.38 in

CC685

Drawn Oval Can

5 µF

2000 V

1.97 in

3.66 in

5.25 in

2 in

1.38 in

CC688

Drawn Oval Can

1 µF

5000 V

1.91 in

2.91 in

4 in

2 in

1.38 in

CC689

Drawn Oval Can

2 µF

5000 V

1.97 in

3.66 in

5 in

2 in

1.38 in

CC686

Drawn Rectangular Can

10 µF

2000 V

3.19 in

3.75 in

5.25 in

2 in

2.00 in

CC687

Drawn Rectangular Can

20 µF

2000 V

3.75 in

4.56 in

7 in

2 in

2.00 in

CC690

Drawn Rectangular Can

5 µF

5000 V

3.19 in

3.75 in

6.25 in

2 in

2.00 in

CC691

Drawn Rectangular Can

10 µF

5000 V

3.75 in

4.56 in

7.25 in

2 in

2.00 in

CC692

Drawn Rectangular Can

1 µF

10000 V

3.19 in

3.75 in

5.5 in

2 in

2.00 in

CC693

Drawn Rectangular Can

2 µF

10000 V

3.75 in

4.56 in

7 in

2 in

2.00 in

CC CUSTOM

CC Series Oil-Filled  Capacitors

N/A

N/A

N/A

N/A

N/A

N/A

N/A
